Appendix A – Site Plan (Formwell / 898 & 914 Klahanie Drive)

Original PDF

Illustrative conceptual site plan for the proposed 58-townhouse development showing unit layout, internal strata road, pedestrian connections and open space areas.

Key facts

  • Shows internal strata loop road accessed via Greystone Place
  • Indicates dark green areas as protected open space (30% target)
  • Pedestrian pathway proposed connecting to Klahanie Drive

Appendix A – Site Plan

Site plan map showing proposed multi-building residential development layout with internal roads, parking, landscaping, a park dedication area, and Klahanie Drive
Site plan map showing proposed multi-building residential development layout with internal roads, parking, landscaping, a park dedication area, and Klahanie Drive

Visible text on the page

  • Site Plan Concept Scale 1:400
  • Park Dedication Area
  • Klahanie Drive
  • Plan 23265
  • Plan EPP89594
  • Langford where it all happens.
Page 19
